Main Params |
Photo |
|
|
Car name |
Autocam 3101
|
Fiat 500
|
Car type |
passenger cars
|
passenger cars
|
Car body type |
suv
|
cabriolet 500C Abarth
|
Model |
avtokam
|
fiat
|
Variant |
3101
|
500
|
Modification |
2.0 MT (115 hp)
|
1.4 AT (135 hp)
|
Release of cars |
1990
|
2007
|
The end of production |
1993
|
2015
|
Engine |
Boost type |
No |
turbocharging |
Compression ratio |
9.8 |
11 |
Cylinder arrangement |
in-line |
in-line |
Cylinder diameter and piston stroke, mm |
86 × 86 |
72 × 84 |
Engine capacity, cm³ |
1998 |
1368 |
Engine power supply system |
distributed injection |
distributed injection |
Engine type |
petrol |
petrol |
Maximum power, hp/kW at rpm |
115 / 85 at 5500 |
135 / 99 at 5500 |
Maximum torque, N*m at rpm |
167 at 2500 |
206 at 3000 |
Number of cylinders |
4 |
4 |
Number of valves per cylinder |
4 |
4 |
General information |
Brand country |
Russia |
Italy |
Car class |
J |
A |
Number of doors |
3 |
3 |
Performance indicators |
Acceleration to 100 km/h, s |
No |
8.1 |
Fuel type |
Super (95) |
Super (95) |
Maximum speed, km/h |
No |
205 |
Sizes in mm |
Ground clearance |
No |
140 |
Height |
1670 |
1488 |
Length |
3430 |
3546 |
Wheel size |
No |
175 / 65 / R14 185 / 55 / R15 |
Wheelbase |
2160 |
2300 |
Width |
1550 |
1627 |
Suspension and brakes |
Front brakes |
drum |
disc |
Rear brakes |
No |
disc |
Type of front suspension |
independent, spring |
independent, spring |
Type of rear suspension |
dependent, spring |
semi-independent, torsion |
Transmission |
Drive type |
rear |
front |
Number of gears |
4 |
6 |
Transmission |
mechanical |
automatic |
Volume and weight |
Fuel tank capacity, l |
No |
35 |
Trunk volume min/max, l |
No |
185 |
