The minivan SWB Ford Tourneo Connect 2009 - 2013 year modification 1.8 MT (110 hp)

Engine
Engine type	diesel
Engine location	front, transverse
Engine capacity, cm³	1753
Boost type	turbocharging
Maximum power, hp/kW at rpm	110 / 81 at 3500
Maximum torque, N*m at rpm	250 at 1500 - 3200
Cylinder arrangement	in-line
Number of cylinders	4
Number of valves per cylinder	2
Engine power supply system	engine with undivided combustion chambers (direct fuel injection)
General information
Brand country	USA
Model assembly	Turkiye
Car class	M
Number of doors	5
Performance indicators
Fuel consumption, l city / highway / combined	7.2 / 5.3 / 6
Fuel type	diesel fuel
Maximum speed, km/h	169
Acceleration to 100 km/h, s	12.5
Sizes in mm
Length	4275
Width	1795
Height	1815
Wheelbase	2664
Ground clearance	166
Front track width	1505
Rear track width	1552
Wheel size	195 / 65 / R15
Suspension and brakes
Type of front suspension	independent, spring
Type of rear suspension	semi-independent, spring
Front brakes	disk ventilated
Rear brakes	drum
Transmission
Transmission	mechanical
Number of gears	5
Drive type	front
Volume and weight
Fuel tank capacity, l	60
Curb weight, kg	1511
Trunk volume min/max, l	1400 / 2600
Gross weight, kg	2110

Ford Tourneo Connect: A Versatile and Efficient Minivan

The Ford Tourneo Connect is a compact minivan that combines practicality, efficiency, and reliability. Produced between 2009 and 2013, this model is designed for families and individuals who need a spacious yet agile vehicle. Assembled in Turkey, the Tourneo Connect is a testament to Ford's global engineering prowess, offering a blend of American design and European efficiency. With its diesel engine, front-wheel drive, and robust build, this minivan is a solid choice for those seeking a dependable and versatile car.

Performance and Efficiency

Under the hood, the Ford Tourneo Connect is powered by a 1.8-liter turbocharged diesel engine, delivering 110 horsepower and 250 Nm of torque. This engine ensures a smooth and responsive driving experience, with acceleration from 0 to 100 km/h in 12.5 seconds and a top speed of 169 km/h. The diesel engine is not only powerful but also fuel-efficient, with a combined fuel consumption of 6 liters per 100 kilometers. Whether navigating city streets or cruising on the highway, the Tourneo Connect offers a balanced performance that prioritizes both power and economy.

Spacious and Practical Design

The Tourneo Connect's minivan body type provides ample space for passengers and cargo. With five doors and a wheelbase of 2664 mm, this vehicle offers a comfortable ride for up to seven passengers. The trunk volume is impressive, ranging from 1400 liters to a maximum of 2600 liters, making it ideal for family trips or transporting bulky items. The car's dimensions—4275 mm in length, 1795 mm in width, and 1815 mm in height—ensure a spacious interior without compromising maneuverability.

Comfort and Safety Features

This minivan is equipped with a range of features designed to enhance comfort and safety. The independent front suspension and semi-independent rear suspension provide a smooth ride, while the ventilated front disc brakes and rear drum brakes ensure reliable stopping power. The Tourneo Connect also includes a 60-liter fuel tank, allowing for longer journeys without frequent refueling stops. Additionally, the car's ground clearance of 166 mm makes it suitable for various road conditions, from urban streets to rural paths.

Pros and Cons

Pros:
- Fuel-efficient diesel engine with low combined consumption of 6 liters per 100 km.
- Spacious interior with flexible seating and cargo options.
- Reliable performance with a top speed of 169 km/h and smooth acceleration.
- Robust suspension and braking system for enhanced safety and comfort.
- Versatile design suitable for both city driving and long-distance travel.
Cons:
- Acceleration to 100 km/h in 12.5 seconds may feel sluggish for some drivers.
- Drum rear brakes, while reliable, are less advanced compared to disc brakes.
- Limited production years (2009-2013) may affect availability of used models.

Conclusion

The Ford Tourneo Connect is a well-rounded minivan that excels in practicality, efficiency, and comfort. Its diesel engine, spacious interior, and reliable performance make it an excellent choice for families and individuals alike. While it may not be the fastest or most luxurious option on the market, its versatility and affordability make it a standout in its class. Whether you're navigating city streets or embarking on a road trip, the Tourneo Connect is a dependable companion that delivers on all fronts.
