The sedan Toyota Carina ED 1993 - 1998 year modification 1.8 AT (120 hp)

Engine
Engine type	petrol
Engine capacity, cm³	1838
Boost type	No
Maximum power, hp/kW at rpm	120 / 88 at 6000
Maximum torque, N*m at rpm	162 at 4600
Cylinder arrangement	in-line
Number of cylinders	4
Number of valves per cylinder	4
Engine power supply system	distributed injection
Compression ratio	9.5
Cylinder diameter and piston stroke, mm	82.5 × 86
General information
Brand country	Japan
Car class	D
Number of doors	4
Performance indicators
Fuel type	Super (95)
Sizes in mm
Length	4500
Width	1740
Height	1325
Wheelbase	2535
Ground clearance	145
Front track width	1510
Rear track width	1490
Wheel size	185 / 70 / R14
Suspension and brakes
Type of front suspension	independent, spring
Type of rear suspension	independent, spring
Front brakes	disk ventilated
Rear brakes	drum
Transmission
Transmission	automatic
Number of gears	4
Drive type	front
Volume and weight
Fuel tank capacity, l	60

Overview of the Toyota Carina ED

The Toyota Carina ED, produced between 1993 and 1998, is a classic Japanese sedan that combines reliability, efficiency, and practicality. As a member of the D-class segment, this car is designed for those who value comfort and performance in a compact package. With its 1.8-liter petrol engine and automatic transmission, the Carina ED offers a smooth driving experience, making it an excellent choice for both city commutes and longer journeys.

Performance and Engine Specifications

Under the hood, the Toyota Carina ED features a 1.8-liter inline-4 petrol engine, delivering 120 horsepower at 6000 rpm and a maximum torque of 162 N*m at 4600 rpm. The engine is equipped with a distributed injection system, ensuring efficient fuel delivery and optimal performance. With a compression ratio of 9.5, this engine strikes a balance between power and fuel economy. The car accelerates smoothly, thanks to its 4-speed automatic transmission, making it a pleasure to drive in various conditions.

Design and Dimensions

The Carina ED boasts a sleek and timeless design, with a length of 4500 mm, a width of 1740 mm, and a height of 1325 mm. Its wheelbase of 2535 mm ensures a stable and comfortable ride, while the ground clearance of 145 mm allows for confident handling on uneven roads. The car's 185/70/R14 wheels provide excellent grip and stability, enhancing both safety and performance.

Interior and Comfort

As a sedan, the Toyota Carina ED offers ample space for passengers and luggage. The independent spring suspension system, both at the front and rear, ensures a smooth and comfortable ride, even on bumpy roads. The car's interior is designed with practicality in mind, featuring a straightforward layout and high-quality materials that have stood the test of time.

Safety and Braking System

Safety is a priority in the Toyota Carina ED. The car is equipped with ventilated front disc brakes and rear drum brakes, providing reliable stopping power in various driving conditions. The combination of these braking systems ensures that the car remains stable and secure, even during sudden stops.

Fuel Efficiency and Capacity

The Carina ED is designed with fuel efficiency in mind. Its 60-liter fuel tank allows for extended driving ranges, while the use of Super (95) fuel ensures optimal engine performance. This makes the car an economical choice for daily commutes and long-distance travel.

Pros and Cons

Pros: Reliable and durable engine, smooth automatic transmission, comfortable ride, spacious interior, and excellent fuel efficiency.
Cons: Limited ground clearance may not be suitable for rough terrains, and the rear drum brakes may require more maintenance compared to disc brakes.

Conclusion

The Toyota Carina ED is a well-rounded sedan that offers a blend of performance, comfort, and reliability. Its timeless design, efficient engine, and practical features make it a great choice for those seeking a dependable vehicle for everyday use. Whether you're navigating city streets or embarking on a road trip, the Carina ED is sure to deliver a satisfying driving experience.
